EC65 Hollow Shaft Incremental Encoder

  • Series:EC65
  • Format:See the following profile
  • Specifications

    Model: EC65 series
    Name:

    EC65 Hollow Shaft Incremental Encoder

    Main Specifications:

    Dimensions: φ65mm

    Rated voltage: DC 10V

    Number of detent: 30

    Pulses: 15

    Working temperature: -40°C~85°C

    Rotational life: 50,000 cycles Min

    Product Features:

    Smooth rotational feel and highly reliable performance;

    Hollow encoder to enable flexible design in the center ring.

    Applications:

    Automotive electronics, household appliances and other related

    electronic devices.

    EC65 Hollow Encoder Product Specifications

    ONE、MECHANICAL CHARACTERISTIC
    1. Rotational Torque: 400±200gf.cm
    2. Number of detent: 30 (Step angle: 12±3°)
    3. Shaft wobble: 0.3mm MAX
    4. Shaft play: 4° Max

    TWO、ELECTRICAL CHARACTERISTIC
    1. Resolution: 15 pulses/360°;
    2. Phase difference: ≥6ms
    3. Rated voltage: DC 10V
    4. Insulation Resistance: 10M? 1 Minute at  DC 500V
    5. Dielectric Voltage: 1 Minute at AC 500V

    THREE、ENDURANCE CHARACTERISTIC
    1. Rotational life: 50,000 cycles Min

    Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".

    Download EC65 Hollow Encoder.pdf

    EC65 Hollow Encoder Specification
